YYW Series Thermal Oil Boiler Gas Oil Fired Organic Heat Carrier Furnace

Name: YYW Series Thermal Oil Boiler Gas Oil Fired Organic Heat Carrier Furnace
Brand: Yinchen
Price: 5000 USD

China YYW Series Thermal Oil Boiler Gas Oil Fired Organic Heat Carrier Furnace wholesale

Brand Name : Yinchen

Model Number : YYW

Certification : ISO SGS CE

Place of Origin : HENAN

MOQ : 1

Price : usd 5000-59800 set

Payment Terms : L/C, T/T, MoneyGram

Supply Ability : 5000 set month

Delivery Time : 1-20 working days

Packaging Details : 1.Package: Regular package or nut package; 2.Transportation: By land or by sea , it depends on the exporting areas.

Pressure : Low Pressure

Usage : Industry

Capacity : 0.21-1.9 m³

Type : Horizontal

Suitable Fuel : gas, oil

Design Pressure : 1.0 Mpa

Output : Thermal Oil

Max Working temperature : 350℃

Circulating Oil : 40-200 m³/h

System Installed Capacity : 14kw, 22kw, 40kw, 66kw, 70kw

Contact Now

YYW Series Gas Oil fired Organic Heat Carrier Furnace Thermal Oil Boiler

Product Description

1. It is fast-assembly forced circulating oil/gas fired boiler with large heating area and compact structure.
2. The heating area is formed by the closely arranged coils from the inside, middle and outside directions. The inner coil is radiation heating area. The middle and outside coils and the the inner coil surface form the convection heating area.
3. The fuel is fired and releases heat in the combustion chamber that formed by inner coils. After taking in most heat through radiation heating area, the high temperature smoke will be into the convection heating area and exchanges heat.
4. It has the four-return design with high efficiency, which can realize the comprehensive evenly heating- up with low thermal inertia.
5. The air goes into the boiler from the air inlet of the burner of the boiler’s front part, and then reaches to the back part and involves into firing through the clamp cover of between the inner and outside layer of heat-carrier boiler. In this process the air forms into four returns and finally is injected through the chimney.

technical parameters

Type		YYW0.24 (20)	YYW0.35 (30)	YYW0.6 (50)	YYW0.9 (75)	YYW1.2 (100)	YYW1.5 (235)	YYW1.8( 150)	YYW2.5 (200)	YYW3 (250)
Rated thermal Power(MW)		0.24	0.35	0.6	0.9	1.2	1.5	1.8	2.5	3.0
Thermal efficiency(%)		90	90	90	90	90	90	90	90	90
Rated steam Pressure(Mpa)		1.0	1.0	1.0	1.0	1.0	1.0	1.0	1.0	1.0
Maximum working Temperature(℃)		350	350	350	350	350	350	350	350	350
Capacity(m³)		0.21	0.25	0.28	0.44	0.64	0.793	1.25	1.76	1.90
Circulating oil(m³/h)		40	40	80	80	80	100	100	200	200
Piping connection Diameter(DN)		100	100	100	100	125	125	125	150	150
System installed Capacity(kw)		14	14	22	22	40	40	40	66	70
Size	Diameter	1016	1016	1216	1416	1716	1716	2000	2000	2000
Size	Height	2050	2350	2450	2900	3300	3900	4100	5100	5300

YYW Series Thermal Oil Boiler Gas Oil Fired Organic Heat Carrier Furnace

Company Information

Basic Information:
Product or Series (we sell): Grade B Boiler (Steam Boiler, Hot Water
Boiler, Thermal Oil Heater)
Brand: YINCHEN
Number of Employee: above 350
Factory Size: more than 60,000square meter
Factory Location: Henan Taikang County Industry Cluster
Number of Production Lines: above 10

Customer Visiting

Our Services

Consultation service: Experienced technicians guidance is available on the phone, and on the internet.
Installation service: One or more engineers will be dispatched to the installation site to help install the customers’ boilers.
Training service: We also provide necessary training about boiler operation and daily maintenance to local workers.
Warm service: Based on customers’ request and budget, our experts make efficient, reliable solutions, and we produce strictly following customers’ order. Every customer has the chance to visit our workshops before placing the order.
